Description
| Radio Specifications | |
|---|---|
| Range | 4Km LoS (2.5mi) |
| Frequency Band | 868.050 – 869.950MHz |
| Encryption method | 128-bit AES |
| HMI | |
|---|---|
| Indication | Frontal panel LED
Internal Service LED |
| Configuration | Internal micro USB connector |
| Power Supply | |
|---|---|
| External | 5 to 24V DC ± 5% |
| Maximum current | 500mA DC @ 5V DC / 100mA DC @ 24V DC |
| Operating Conditions | |
|---|---|
| Operating Temperature | -30 to 80ºC |
| Housing | |
|---|---|
| Protection Index | IP65 |
