Descriere
| RS-485 Communication | |
|---|---|
| Protocol | Modbus RTU (master) |
| Baudrate | 4,8 to 115,2 kbit/s (configurable) |
| Parity | none/even/odd |
| Stop bits | 1 (even/odd) or 2 (none) |
| Addresses | 1 to 247 |
| Ethernet Communication | |
|---|---|
| Interface | Ethernet port (RJ45) |
| Speed | 100 mbps |
| Modbus TCP/IP Port | 1502 |
| Power Supply | |
|---|---|
| External | 12 to 24V DC ± 5% |
| Maximum current | 100mA DC to 24V DC / 200mA DC to 12V DC |
| IoT Connectivity | |
|---|---|
| Integration with Tekon IoT Platform | |
| REST Api | |
| HMI | |
|---|---|
| Indicators | Frontal panel LED |
| Communication | Ethernet |
| Operating conditions | |
|---|---|
| Operating Temperature | 0ºc to 80ºc |
| Protection Index | |
|---|---|
| IP40 | |
